Huawei EchoLife HG8546M Wi-Fi Router | ONT | XPON/GPON/EPON | High-Speed 10/100/1000 Mbps
Brand | Huawei |
---|---|
Model | EchoLife HG8546M |
Number of LAN ports | 4x 10/100BaseTX (RJ45) |
PON standard | XPON |
Wireless network standards | IEEE 802.11g, IEEE 802.11n, IEEE 802.11b, |
USB port | 1x USB |
VoIP ports | 1x POTS |
Features
- Same Day Delivery (Lahore)
- Trusted Shipping
- Great Recent Rating
Huawei HG8546M ONT Router – High-Speed Connectivity for Pakistan!
Looking for reliable, high-speed internet for your home or office? The Huawei EchoLife HG8546M ONT Router is the perfect choice for staying connected across all your devices. Designed with the latest technology, this Wi-Fi router delivers seamless internet, voice, and Wi-Fi services at a price that’s hard to beat in Pakistan.
Key Features of Huawei HG8546M:
- GPON Connectivity: Utilizes Gigabit Passive Optical Network (GPON) technology to deliver ultra-broadband access with downstream speeds up to 2.5 Gbps and upstream speeds up to 1.25 Gbps.
- Ethernet Ports: Equipped with one Gigabit Ethernet (GE) port (1x RJ45 1000 Mb/s) and three Fast Ethernet (FE) ports (3x RJ45 100 Mb/s) for wired device connections.
- Voice Support: Includes one POTS (Plain Old Telephone Service) port (1x RJ11) for VoIP services, supporting both SIP and H.248 protocols.
- USB Interface: Features one USB port for connecting external storage devices or printers.
- Wi-Fi Capability: Supports 2.4 GHz Wi-Fi with 802.11 b/g/n standards, offering wireless speeds up to 300 Mbps.
- VoIP-Ready: The RJ11 port supports VoIP, ensuring clear voice calls and easy communication for remote work or family calls.
Huawei HG8546M Price in Pakistan
Get the Best Price on the Huawei HG8546M in Pakistan at Hafeez Center
The Huawei HG8546M ONT Router is available at Hafeez Center for only ₨ 5,400, making it a top choice for reliable, high-speed internet at an affordable price. Tailored for the Pakistani market, this router delivers exceptional value with all its high-performance features. Whether you’re streaming, browsing, or working from home, this router provides stable, secure, and high-quality internet connectivity at a price that’s easy on the budget.
Ready to upgrade your connection?
Shop the Huawei HG8546M ONT Router at Hafeez Center and experience high-speed, reliable connectivity for only ₨ 5,400!
Here is a detailed technical specifications chart for the Huawei HG8546M ONT Router:
Specification | Details |
---|---|
Model | Huawei EchoLife HG8546M |
Dimensions | 176 mm (W) x 138 mm (D) x 28 mm (H) |
Weight | Approximately 500 grams (including power adapter) |
Power Supply | Input: 100–240 V AC, 50–60 Hz Output: 12 V DC, 1.5 A |
Power Consumption | ≤15 W (fully loaded) |
Operating Temperature | 0°C to 50°C |
Operating Humidity | 5% to 95% RH (non-condensing) |
GPON Interface | SC/APC connector Downstream: 2.488 Gbps Upstream: 1.244 Gbps Wavelengths: Downstream 1490 nm, Upstream 1310 nm Compliant with ITU-T G.984.2, Class B+ |
Ethernet Ports | 1 x GE (10/100/1000 Mbps) RJ45 port 3 x FE (10/100 Mbps) RJ45 ports Auto-negotiation and MDI/MDIX auto-sensing |
POTS Port | 1 x RJ11 port for VoIP services Supports SIP and H.248 protocols Ringing voltage: 65 V RMS Maximum REN: 5 |
USB Port | 1 x USB 2.0 port Supports external storage devices and printers |
Wi-Fi | 2.4 GHz frequency band IEEE 802.11 b/g/n standards Maximum wireless speed: 300 Mbps 2 x 2 MIMO with external antennas (2 dBi gain each) |
Security Features | Firewall capabilities MAC address filtering URL filtering WPA-PSK/WPA2-PSK encryption |
Quality of Service (QoS) | Supports traffic classification and prioritization Ensures optimal performance for voice, video, and data services |
Management | Local management via web interface Remote management through TR-069 and OMCI protocols Supports firmware upgrades and configuration backups |
Compliance | CE, FCC, and RoHS certifications |
Huawei EchoLife HG8546M Will Power Up Your Connection!
The Huawei EchoLife HG8546M is an Optical Network Terminal (ONT) designed for Fiber-to-the-Home (FTTH) deployments, providing high-speed internet, voice, and Wi-Fi services for residential and small office users.
Technical Specifications:
- Dimensions: Approximately 176 mm x 138 mm x 28 mm.
- Power Supply: Operates with a 12V, 1.5A power adapter.
- Operating Environment: Designed to function within a temperature range of 0°C to 50°C and humidity levels between 5% and 95% (non-condensing).
- Weight: Weighs less than 500 grams.
Additional Features:
- Quality of Service (QoS): Supports QoS features to prioritize traffic, ensuring optimal performance for voice, video, and data services.
- Security: Offers robust security measures, including firewall capabilities and support for various encryption protocols.
- Management: Provides local management via a web interface and remote management through TR069 and OMCI protocols.
The HG8546M is a versatile ONT suitable for delivering high-speed internet, voice, and Wi-Fi services in FTTH networks, ensuring a seamless and reliable user experience.
